GE DS200UCPBG6AFB I/O Engine CPU Board

The GE DS200UCPBG6AFB is an I/O engine CPU board manufactured by General Electric (GE) and is part of the Mark V series turbine control system. The specific introduction is as follows:

Functional features: This board has data processing and I/O control functions, which can process input signals and output control signals to achieve control of turbine-related equipment. It uses a specific microprocessor and multiple programmable read-only memory (PROM) modules to execute complex control logic and algorithms to ensure the stable operation of the turbine system.

Hardware configuration: There is a dual in-line memory module (DIMM) connector on the board, which can be used to expand memory to meet data storage and processing needs. It is also equipped with a switch block containing 7 switches, which can be used to set the board's operating mode, address and other parameters. In addition, there is a 34-pin connector and a connector for connecting other boards to facilitate communication and data interaction with other circuit boards.

Voltage regulation: The voltage limiting technology commonly used in the Mark V series is used to handle voltage regulation, which ensures that the board operates within a stable voltage range and enhances the stability and anti-interference ability of the board.

Product status: Although the Mark V series is widely used, the Mark V turbine control system series to which this board belongs has been gradually discontinued and is an outdated legacy product series, but it is still used in some old systems due to its reliability and stability.
