ABB 5SHX1960L0004 3BHL000390P0104 IGCT Module

ABB 5SHX1960L0004 3BHL000390P0104 IGCT Module is a high-performance integrated gate-commutated thyristor module. The following is its relevant information:

Basic Information

Product Model: 5SHX1960L0004 is the model of the IGCT module, and 3BHL000390P0104 is the corresponding product number.

Country of Origin: Switzerland.

Dimensions: 29cm×32.3cm×3.5cm.

Weight: 0.85kg.

Technical Features

High voltage and high current capability: With a nominal voltage of 4.5kV and a nominal current of 1960A, it can handle high voltage and high current, and is suitable for high-voltage and high-power power electronics applications.

Low loss: Using advanced IGCT technology, it has low turn-on and turn-off losses, can achieve high-efficiency energy conversion, and helps reduce the operating cost and heat dissipation requirements of the system.

High switching frequency: The ability to operate at a higher switching frequency helps improve the performance and power density of power electronic equipment, allowing the system to respond to control signals more quickly.

Short-circuit tolerance: With short-circuit tolerance, it can withstand a certain period of short-circuit current when a short-circuit fault occurs, providing sufficient time for the protection circuit to operate and improving the reliability of the system.

Reverse blocking capability: With reverse blocking capability, it can prevent current from flowing in the reverse direction, ensuring the normal operation of the module under various working conditions.

Thermal stability: With good thermal stability, it can maintain stable performance under different ambient temperatures and load conditions, effectively solving the heat dissipation problem during high-power operation.
