ACQUISITION LOGIC AL81G Analog-to-Digital Converter (ADC) board
Delivery time 3 days
Product origin New/used
Email plcru@foxmail.com
Mobile/wechat /WhatsApp +86 18185397189
The ACQUISITION LOGIC AL81G is a high-performance analog-to-digital converter bo
The ACQUISITION LOGIC AL81G is a high-performance analog-to-digital converter board. Here is a detailed description:
Basic Information
Type: Single-channel, high-resolution A/D converter board.
Series: OKOS AL8xGTE series sampler boards.
Bus: Supports PCI Express x1 bus.
Dimensions: Approx. 220mm × 167.6mm × 21.9mm.
Weight: 500 grams.
Operating Temperature: 0℃ to 50℃.
Storage Temperature: -40℃ to 85℃.
Performance Parameters
Sampling Rate: Up to 1GS/s.
Resolution: 8 bits.
Input Impedance: 50 ohms.
Input Bandwidth: 100MHz.
Onboard Memory: 64MSamples.
Trigger Modes: Supports software triggering, hardware triggering, signal threshold triggering, encoder triggering, etc.
Vertical Sensitivity: 2mV/div to 10V/div. Rise Time: ≤3.5ns.
Features
Multiple Sampling Rate Options: In addition to the maximum sampling rate of 1GS/s, it also offers sampling rate options of 500, 250, and 100MS/s.
Rich Trigger Functions: Supports pre-triggered, post-triggered, delayed sampling, and automatic re-arming functions to meet various sampling requirements.
DSP Functions: Supports digital signal processor functions such as interpolation and programmable peak detectors.
Connectivity Interfaces: Employs BNC connectors for analog signal input and trigger input/output, while also supporting communication interfaces such as USB 3.0, Ethernet, and serial interfaces for easy data transmission and system integration.
Application Areas: Widely used in scientific research, electronic testing, radar systems, communication systems, and other fields requiring high-precision, high-speed data acquisition.
