CPCI-AC-6U-500 900-7002-99 Power Module

The CPCI-AC-6U-500 is a 6U Compact PCI AC input power supply module, possibly associated with the 900-7002-99 model number. It is used to provide power for Compact PCI systems. The following are some of its features:

Power Output: Based on the "500" in the model number, it likely provides 500W of power, capable of providing stable power to connected Compact PCI devices, meeting the power needs of various boards and other devices.

Input Characteristics: These modules typically have a wide input voltage range, potentially 90-264V AC, with a frequency of 47-63Hz, adapting to various AC power supply environments and providing good compatibility.

Output Characteristics: It may provide multiple standard output voltages, such as 3.3V, 5V, 12V, and -12V, to meet the power requirements of different Compact PCI devices. The output current of different voltages will vary depending on the design. For example, a 5V output may have a higher current to support devices with higher 5V power requirements.

Standard Compliance: Compliant with the PICMG 2.11 standard, ensuring electrical and mechanical compatibility with other CompactPCI system components, facilitating system integration and expansion.

Application Scenarios: Due to its high reliability and stability, as well as its adaptability to harsh environments, it is often used in power-demanding applications such as industrial control, defense, and aerospace, providing stable power supply to CompactPCI devices in these systems and ensuring normal system operation.

Safety and Protection: Built-in input and output protection and filtering functions, such as overvoltage protection, overcurrent protection, and short-circuit protection, may be included to prevent damage to the power module and connected devices due to abnormal conditions. Filtering also reduces power supply noise and improves power quality.
