Here is more information about Honeywell's 05701-A-0284 SIEGER single-channel control card:

Functional Overview:

This is a catalytic sensor driven single-channel control card that is mainly used to condition the incoming catalytic sensor signal and provide the necessary power to the sensor.

The control card integrates the circuits to generate the voltage and current required to drive the sensor, and can also obtain the sensor signal and scale it to a standard output.

Performance Parameters:

Input Signal: Adapts to catalytic sensor signal input.

Output Signal: The sensor signal is processed and output as a standard signal. The specific output specifications may vary depending on the configuration.

It can usually be electronically set to 0-20mA or 4-20mA output, which can be used to connect to equipment such as chart recorders.

Power Supply: Usually a suitable DC power supply is provided externally. The specific voltage and other parameters may require reference to the product manual or device label,

which generally matches the power supply specifications of the relevant system.

Power Consumption: There is no exact typical or maximum value data, but as a single-channel control card,

the power consumption is relatively low under normal working conditions to meet the energy saving and heat dissipation requirements in industrial environments.

Application fields:

Widely used in modern industrial fields such as electricity, petroleum, chemical industry, metallurgy, papermaking, textile, etc., for signal processing and control of various catalytic sensors,

so as to realize the monitoring and control of relevant parameters in industrial processes.
