EMERSON 1C31113G01 OVATION DCS Card | Analog Input Module

EMERSON 1C31113G01 is an analog input module in Emerson Ovation DCS system, belonging to the DeltaV S series I/O family. It is mainly used to convert analog signals in the field into digital signals for processing and control by the control system, and is widely used in the field of industrial automation. The relevant introduction is as follows:

Channel and signal type: It has 16 differential input channels, which can process 4-20mA current loop, 0-10VDC voltage signal and J, K, T, E type thermocouple input signals.

Resolution and accuracy: It adopts 24-bit analog-to-digital conversion, with high resolution and measurement accuracy of ±0.05% of the full scale. It can accurately collect and convert analog signals and provide accurate data for the control system.

Physical characteristics: The size is 178mm (width) × 102mm (height) × 25mm (depth), and the weight is about 0.9kg. It adopts DIN rail installation, which is easy to install in the control cabinet.

Working environment: The working temperature range is - 40℃ to 70℃, the humidity range is 5%-95% non-condensing, and it has an IP20 protection level, which can adapt to harsh industrial environments.
