Vibro-meter 200-595-100-014 200-595-072-122 VM600 CPUM CPU Board VMF-CPUM
Delivery time 3 days
Product origin New/used
Email plcru@foxmail.com
Mobile/wechat /WhatsApp +86 18185397189
The following are the relevant data table information of Vibro-meter 200-595-100
The following are the relevant data table information of Vibro-meter 200-595-100-014 and 200-595-072-122 VM600 CPUM CPU Board VMF-CPUM:
Overview
Product model: VM600 CPUM, including specific models such as 200-595-100-014 and 200-595-072-122.
Functional positioning: It is the core control unit of the VM600 series vibration monitoring system, serving as a system controller and data communication gateway. It is used in the mechanical equipment protection system (MPS) and condition monitoring system (CMS), coordinating data from various sensors and modules to provide real-time vibration monitoring and protection, ensuring the reliable operation of critical mechanical equipment.
Electrical characteristics
Input voltage: There are multiple input voltage versions, including AC input (115/230VAC or 220VDC) and DC input (24VDC and 110VDC), etc. Some data also indicate that the input voltage range is 18-32VDC.
Power: Some data indicate that the power is 125W, while others mention that the power consumption is 10-15W.
Communication interface
Ethernet interface: A main Ethernet connector (8P8C (RJ45)) for communicating with the VM600 MPSX software and/or Modbus TCP and/or Profinet; An auxiliary Ethernet connector (8P8C (RJ45)) for redundant Modbus TCP communication.
Serial interface: A main serial connector (6P6C (RJ11/RJ25)), used for communicating with the VM600 MPSX software through direct connection; Two pairs of serial connectors (6P6C (RJ11/RJ25)) can be used to configure the VM600 rack as a multi-point RS-485 network.
Working environment
Operating temperature: Generally -20 °C to + 70°C, and some data also indicate -40 °C to + 85°C.
Storage temperature: -40°C to + 100°C.
Other features
Anti-interference performance: It has excellent anti-electromagnetic interference capability. Its housing design can resist external electromagnetic fields, ensuring that vibration measurements are not affected and guaranteeing the integrity of the data.
Durability: Designed to withstand harsh industrial environments, it can resist extreme temperatures, high humidity and mechanical shock, and can be installed in harsh conditions such as industrial sites, near heavy machinery or even outdoors.
