EPRO PR6423/003-010 is an eddy current sensor, not a current sensor. It is mainl

EPRO PR6423/003-010 | 9200-02300n | Current Sensors | PR6423-003-010

EPRO PR6423/003-010 is an eddy current sensor, not a current sensor. It is mainly used for monitoring parameters such as vibration and displacement of rotating machinery in the industrial field, not for current measurement. The following is a related introduction:


Working principle: The eddy current sensor and the preamplifier form an oscillator. The amplitude decays as the sensor probe approaches the metal object being measured. The attenuation amplitude is proportional to the distance between the sensor and the object being measured. Non-contact measurement is achieved through this principle.

Functional features: It complies with international general standards such as API 670, DIN 45670, ISO 10817-1, and can be used in explosion-proof environments. The explosion-proof level can reach Eex ib IIC T6/T4. It has the advantages of small size, high reliability, and non-contact measurement.

Measuring range: The measuring range of the PR6423 series sensor is generally 0…±1.0mm to 0…±1.5mm, which can meet the measurement requirements of physical quantities such as radial and axial displacement of the shaft, shaft vibration, and shaft eccentricity.

Technical parameters: Taking the similar model PR6423/000-010 in the same series as an example, its linear measurement range is 2mm, the initial air gap is 0.5mm, the incremental scale factor is 8V/mm (203.2mV/mil) ±5% (temperature range 0 to 45°C), the minimum shaft diameter is 25mm, the target material is usually 42CrMo4 (AISI/SAE 4140) standard ferromagnetic steel, the protection level is IP66, and the operating temperature range is -35 to +200°C (the sensor includes 1 meter cable).

Application areas: Commonly used to measure radial gas and hydraulic turbines, compressors, gearboxes, pumps and fans and other equipment. It can be used with dual-channel bearing vibration measurement modules to monitor bearing vibrations, and can also be provided as input to analysis and diagnostic systems, fieldbus systems, etc.
