B&R 5PC720.1505-K01 Operator Interface

B&R 5PC720.1505 - K01 is an operation interface device launched by B&R, which is a product for human-computer interaction in the field of industrial automation. The following is its relevant information:

Appearance size and weight: The size is about 43.8cm×33.0cm×8.3cm, and the weight is about 6.6kg.

Touch characteristics: It adopts a resistive touch screen, which is a single-point touch type and can meet the basic operation requirements in general industrial scenarios. The linearity error of its touch glass is less than 1.5%, ensuring high touch accuracy. The HMI response speed is less than 10ms, which can quickly respond to user operations.

Working environment adaptability: The working temperature range is -10℃ to +60℃, and the storage temperature range is -20℃ to +70℃. It can adapt to relatively harsh industrial environments, and has good stability whether in high-temperature workshops or low-temperature warehouses.

Electrical characteristics: The input interface has 3 signals, namely 12V DC input VIN, working enable voltage ENB and Panel current control signal DIM. When ENB is 0V, the inverter does not work; when ENB is 3V, the inverter works normally. The DIM voltage range is between 0-5V. By feeding back different DIM values to the PWM controller feedback terminal, the inverter can be controlled to provide different currents to the load.
