Honeywell 10018/E/1 Ethernet Communication Module

I. Product Overview

Model: 10018/E/1

Type: Industrial Ethernet communication module, used to connect the control system with the upper computer, PLC, sensors or other network devices to achieve data interaction and remote monitoring.

Brand series: PlantScape or Experion automation control system components that may belong to Honeywell, compatible with its controllers or distributed control systems (DCS).

Ii. Core Functions

1. Communication protocol support

Standard Protocol

Supports industrial Ethernet protocols such as Ethernet/IP, Modbus TCP, and OPC UA, and is compatible with mainstream industrial network architectures.

It may support SNMP (Simple Network Management Protocol) for device status monitoring.

Customized protocols: Some models support user-defined communication protocols to adapt to non-standard devices.

2. Interfaces and Connections

Physical interface:

Ethernet ports: 1 or 2 RJ45 interfaces, supporting 10/100Mbps adaptive. Some models may support redundant networks (such as dual network port fault tolerance).

Diagnostic indicator lights: Equipped with LED indicator lights such as Link/Act, Power, and communication Status, facilitating on-site fault detection.

Network topology: Supports star, ring or linear topologies to meet the complex networking requirements in industrial environments.

3. Data transmission capability

Data throughput: The typical value is 100Mbps, which meets the requirements of real-time data transmission (such as process parameters, device status, alarm information, etc.).

Data mapping: Supports mapping module register data to the tags (Tag) of the control system to achieve seamless data exchange.

Security features:

Built-in firewall or access control list (ACL) to prevent unauthorized network access.

Support data encryption (such as SSL/TLS) to ensure communication security.
