Bently Nevada 3500/44M 140734-03 Aeroderivative Gt Vibration Monitor

Bently Nevada 3500/44M 140734 - 03 Aeroderivative GT Vibration Monitor is a four-channel vibration monitoring device for aeroderivative gas turbines. Here is a brief introduction:

Functional Features

Multi-channel design: With four channels, it can simultaneously monitor vibrations at multiple locations of an aeroderivative gas turbine, and fully understand the vibration status of the equipment.

Multiple filtering options: Through the 3500 rack configuration software, signal integration, 1X vibration tracking, bandpass vibration and other filtering functions can be realized, and it can be flexibly configured according to different monitoring needs and signal characteristics to improve the accuracy and effectiveness of monitoring.

Dual key phase input: It can accept two independent key phase signal inputs, allowing each pair of channels to use different tracking filters, which helps to more accurately analyze the relationship between the vibration signal and the unit operating status, and provide more abundant information for fault diagnosis.

Powerful alarm function: Up to eight sets of alarm parameters can be configured, including warning and danger set points and alarm delay time, and can be set for specific machine operating modes. When the vibration parameters exceed the set threshold, an alarm signal can be issued in time to remind the operator to take corresponding measures.

Technical Specifications

Channel capacity: 4 vibration sensor inputs, 4 sensors can be connected at the same time, and the vibration of different positions or directions of the machine can be monitored synchronously.

Signal processing: With high-speed processing capabilities, it can analyze vibration data in real time, detect early signs of failure in time, and provide support for preventive maintenance of equipment.

System compatibility: As part of the Bently Nevada 3500 series monitoring system, it can be fully integrated with other components of the series, and can be easily connected to the entire monitoring system to achieve data sharing and collaborative processing.

Physical characteristics: The size is approximately 24.3cm×14.6cm×15.5cm, the weight is 0.8kg, the structure is sturdy, suitable for use in harsh industrial environments, and can adapt to high temperature, vibration, dust and other conditions to ensure long-term stable operation.

Application areas: It is mainly used for vibration monitoring of aviation-derivative gas turbines. It plays an important role in gas turbine power generation, ship power and other scenarios in the fields of electricity, aerospace and other related fields. By real-time monitoring of vibration conditions, it can ensure the safe and stable operation of gas turbines, reduce downtime, and improve the reliability and service life of equipment.
